Patrol C024

Ditch the screens and hit the singletrack — the all-new Carbon Kids’ range from Patrol Mountain is here. We know young riders want to push limits, explore deep, and ride just as hard as the grown-ups. That’s why we built this range to match their ambition — lightweight, trail-ready bikes designed for comfort, confidence, and serious fun from the very first ride.
Find Our Distributors

We’ve seen a couple of custom made carbon bikes for kids, but the Patrol C020 and Patrol C024 could be the world’s first production carbon mountain bikes for kids!

Singletrack

Using a full carbon frame construction, the new C020 and C024 kid’s bikes have high end features like internal cable routing, a tapered head tube, clearance for big tires, and even a bottle cage mount inside the front triangle.” – Bike Rumor



Patrol 024
Head Tube Angle
 67°
Head Tube Length
 105
Top Tube Horizontal
 520
Reach
 355
Standover
 599
Stack
 540
Seat Tube Length
 320
Seat Angle
 73°
Bottom Bracket Height
 284
Bottom Bracket Drop
 -24.9
Chainstay Length
 385
Wheelbase
 1006
FRAME
 PATROL 024 Carbon XC 24, 12×148 Boost
FORK
 MANITOU Junit Comp, 120mm travel
REAR MECH
 SRAM GX, 10s
SHIFTER
 SRAM GX
CHAINSET
 SAMOX, 155mm, 32t
CASSETTE
 Steel, 10s, 11-34t
BRAKES
 SHIMANO MT200
WHEELS
 PATROL RIMS MD30 with PATROL hubs, 32h
TYRES
 VEE Crown Gem, 24×2.6
PRICE
 $1499

*ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
